The MEGA Megascrape is designed as a high capacity box scraper. Compared to the standard Megascraper, it is 150mm taller and 305mm deeper. This increases the internal size from 0.6 cubic meters to 1.2 cubic meters. To stand up to this higher capacity, the gates are secured with three sets of chains and the middle frame has been upgraded with an extra cross member to anchor the chains.
It is automatic in operation as a push and pull scraper, with no levers or catches to operate. It has independently moving sides to follow uneven surfaces and ensure the slurry is retained within the box enclosure.
An A frame is incorporated into the linkage frame, which in turn is mounted on springs to ensure downward pressure on the rubber scraping blades to give a clean scraping action.
MEGA high capacity scraper - reduces time and effort
7FT working width
Twin blade system for automatic push/pull operation
No levers or catches
Independently moving sides to follow uneven surfaces
Weight transfer design ensures positive pressure on blades for a cleaner finish
Fits cat 1 and 2 three point linkage
A frame incorporated into main headstock
Rust and seize free rubber hinges
Available in four working widths
Can be front mounted (brackets sold seperately)
